Caratteristiche tecniche
Hardware | |
---|---|
Model | F1026F |
Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab |
Intertface | 24*10/100M+2*10/100/1000M auto-negotiation RJ45 ports (Auto MDI/MDIX) 2*1000M SFP solts (Combo) |
Transmission media | 10Base-T: Cat. 3 UTP or better, 100Base-TX: Cat.5 UTP or better 1000Base-T: Cat.5e UTP or better, 1000BASE-X: MMF, SMF |
Forwarding rate | 10 Mbps: 14880 pps 100 Mbps: 148800 pps 1000 Mbps: 1488000 pps |
Power Supply | Input: AC:100-240V; 50/60Hz |
Lightning protection | 6kV in Common Mode Protection for 2*GE ports 6kV in Common Mode, 4kV in Di erential Mode Protection for power supply |
Dimension | 440mm *178mm *44mm(L * W * H) |
LED indicato | 1* Power, 26* Link/Act, 3*mode status lights |
Switching capacity | 8.8Gbps |
MAC address table | 16K |
Power consumption | Maximum : 12W (220V) |
Software | |
Store-and-forward | Supported |
Protocol | CDMA/CD |
Mode | M1: Standard mode, the default mode of the switch. In that mode, all ports can communicate with each other. M2: Port-based priority mode, ports 1 to 8 have higher priority than other ports, and all ports can communicate with each other. M3: Port-based VLAN mode, ports 1 to 24 can communicate with uplink ports (ports 25 and 26) but cannot communicate with each other. |
MAC address learning | Auto learning & auto aging |
Loop Guard | Support Hardware Auto loop protection and prevention in M1 |
Others | |
Temperature | Operating temperature: (0 - 40)°C Storage temperature: (-40 - 70)°C |
Humidity | Operating humidity: (10% - 90%) RH, non-condensing Storage humidity: (5% - 90%) % RH, non-condensing |
Certification | CCC, CE, FCC, RoHS |
