CARATTERISTICHE HARDWARE | |
---|---|
Interfaccia | 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE) |
Tasto | Reset |
Alimentazione | • 802.3at PoE • 12V DC (EU Version: 12 V / 1.0 A DC. US Version: 12 V / 1.5 A DC). Note: DC adapter is not included in the package, and is sold separately. |
Consumo energetico | • EU: 13.5 W • US: 14.7 W |
Dimensioni ( L x P x A ) | 6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm) |
Tipo di antenna | Internal Omni • 2.4 GHz: 2× 4 dBi • 5 GHz: 2× 5 dBi |
Tipo di montaggio | • Ceiling /Wall Mounting (Kits included) • Junction Box Mounting |
CARATTERISTICHE WIRELESS | |
---|---|
Standard wireless | IEEE 802.11ax/ac/n/g/b/a |
Frequenza | 2.4 GHz and 5 GHz |
Signal rate | • 5 GHz: Up to 2402 Mbps† • 2.4 GHz: Up to 574 Mbps† |
Funzionalità wireless | • 1024-QAM • 4× Longer OFDM Symbol • OFDMA • Multiple SSIDs (Up to 16 SSIDs, 8 for each band) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS(WMM) • MU-MIMO • HE160 (160 MHz Bandwidth)‡ • Seamless Roaming § • Omada Mesh§ • Band Steering • Load Balance • Airtime Fairness • Beamforming • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client |
Sicurezza wireless | • Captive Portal Authentication§ • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
Potenza di trasmissione | • CE: <20 dBm(2.4 GHz, EIRP) <23 dBm(5 GHz, Band1 & Band2, EIRP) <27 dBm(5 GHz, Band3, EIRP) • FCC: <22 dBm (2.4 GHz) <22 dBm (5 GHz) |
GESTIONE | |
---|---|
Omada App | Yes |
Centralized Management | • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller • Omada Cloud-Based Controller |
Cloud Access | Yes (Through OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller) |
Avvisi e-mail | Yes |
LED ON/OFF | Yes |
Management MAC Access Control | Yes |
SNMP | v1, v2c, v3 |
Log di sistema locale e remoto | Local/Remote Syslog |
SSH | Yes |
Gestione web-based | HTTP/HTTPS |
L3 Management | Yes |
Multi-site Management | Yes |
Management VLAN | Yes |
ALTRO | |
---|---|
Certificazione | CE, FCC, RoHS |
Contenuto della confezione | • EAP653 • Ceiling/Wall Mounting Kits • Installation Guide Note: DC adapter is not included in the package, and is sold separately. |
Requisiti di sistema | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux |
Ambiente | • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
